Water Control Solutions

Control Circuits

& Accessories

Pocket Guide

Irrigation

Water Control Solutions

Browsing through the Pocket Guide

The Pocket Guide was designed with the pages

bound by top spiral, to allow smooth sliding in

& out of your pocket.

The best way to

“browse” while

working with your

Pocket Guide is to

turn the page all

the way back,

Then flip the

Pocket Guide

horizontally to

view the next page.

Valve Type Identification

According to Series

100 Series

Plastic Hydraulic / Electric Control Valves

Single Chamber

200 Series

Plastic Hydraulic / Electric Control Valves

Single Chamber

300 Series

Plastic/Metal Hydraulic / Electric Control Valves

Single or Double Chamber

400 Series

Hydraulic Diaphragm Control Valves

Single Chamber

700 Series

Hydraulic Diaphragm Control Valves

Single or Double Chamber

900 Series

Hydrometers / Automatic Metering Valves

Single Chamber

Water Control Solutions

PC-X-A-P Positioning 3-Way Mini-Pilot Valve, Plastic A-

PC-X-A-M Positioning 3-Way Mini-Pilot Valve, Metal A-

PC-S-A-P

Pressure Reducing Servo 2/3-Way Mini-Pilot Valve, Plastic A-

PC-S-A-M

Pressure Reducing Servo 2/3-Way Mini-Pilot Valve, Metal A-

PC-20-A-P Pressure Reducing 2-Way Mini-Pilot Valve, Plastic

A-

PC-20-A-M

Pressure Reducing 2-Way Mini-Pilot Valve, Metal A-

PC-30-A-P Pressure Sustaining 2-Way Mini-Pilot Valve, Plastic

A-

PC-30-A-M

Pressure Sustaining 2-Way Mini-Pilot Valve, Meta A-

PC-3Q-A-P

Quick Pressure Relief Mini-Pilot Valve, Plastic A-

PC-3Q-A-M Quick Pressure Relief Mini-Pilot Valve, Metal

A-

PC-70-A-P

Paddle Flow Rate Servo Mini-Pilot Valve, Plastic A-

PC-70-A-M Paddle Flow Rate Servo Mini-Pilot Valve, Metal

A-

#X Positioning 3-Way Pilot Valve A-

#2 Pressure Reducing Pilot Valve (^) A-

#3 Pressure Sustaining Pilot Valve A-

#8 Altitude Positioning Pilot Valve A-

3W-SOP 3-Way Shut-Off Pilot for AMV A-

A Accesories

Water Control Solutions

N05-Z Hydraulic Control Valve B-

900-DO Automatic Metering Valve (AMV) B-

900-DD

Automatic Metering Valve (AMV) for Sequential Irrigation B-

N05-54-KX Hydraulic Control Valve N.C. with Hydraulic Relay

B-

N05-54-RXZ

Hydraulic Control Valve N.C. with Hydraulic Relay B- N10-KX Solenoid Controlled Valve B-

N10-N1-2W

Solenoid Controlled Valve with 2-Way Internal Control B- N10-RX Solenoid Controlled Valve (^) B-8-

B On/Off Control Valves

N20-K Pressure Reducing 2-Way Valve C-

N20-R Pressure Reducing 2-Way Valve C-2-

N20-50-K

Pressure Reducing 2-Way Valve with Hydraulic Control C-

N20-50-R Pressure Reducing 2-Way Valve with Hydraulic Control

C-5-

N20-54-K

Pressure Reducing 2-Way Valve N.C. with Hydraulic Relay C-

N20-54-R Pressure Reducing 2-Way Valve N.C. with Hydraulic Relay C-

N20-55-K Pressure Reducing 2-Way Valve with Solenoid Control

C-

C Pressure Reducing Valves

Water Control Solutions

N20-55-R Pressure Reducing 2-Way Valve with Solenoid Control

C-10-

920-D2-R

Pressure Reducing 2-Way Valve Automatic Metering Valve (AMV) C- N20-KXZ Pressure Reducing 3-Way Valve C-

N20-RXZ Pressure Reducing 3-Way Valve C-

N20-50-KXZ

Pressure Reducing 3-Way Valve with Hydraulic Control C-

N20-50-RXZ Pressure Reducing 3-Way Valve with Hydraulic Control C-

N20-54-KX Pressure Reducing 3-Way Valve N.C. with Hydraulic Relay

C-

N20-54-RXZ

Pressure Reducing 3-Way Valve N.C. with Hydraulic Relay C-

N20-55-KX Pressure Reducing 3-Way Valve with Solenoid Control (982/985 Only)

C-

N20-55-KX

Pressure Reducing 3-Way Valve with Solenoid Control C-

N20-55-RX Pressure Reducing 3-Way Valve with Solenoid Control (982/985 Only)

C-

N20-55-RX Pressure Reducing 3-Way Valve with Solenoid Control

C-22-

920-D0-KX

Pressure Reducing 3-Way Valve Automatic Metering Valve (AMV) C-

920-D2-RX Pressure Reducing 3-Way Valve Automatic Metering Valve (AMV)

C-

N20-bKZ Pressure Reducing 2/3-Way (Servo) Valve C-

N20-50-bKZ Pressure Reducing 2/3-Way (Servo) Valve with Hydraulic Control

C-

N20-54-bK

Pressure Reducing 2/3-Way (Servo) Valve N.C. with Hydraulic Control C-

C Pressure Reducing Valves

Water Control Solutions

N23-54-KX Pressure Reducing & Sustaining 3-Way Valve (N.C. with Hydraulic Relay)

D-

N23-55-KX

Pressure Reducing & Sustaining 3-Way Valve with Solenoid Control (982/5 Only) D-

N23-55-RXZ Pressure Reducing & Sustaining 3-Way Valve with Solenoid Control

D-17-

D Pressure Reducing & Sustaining Valves

N30-K Pressure Sustaining 2-Way Valve E-

N30-R Pressure Sustaining 2-Way Valve E-2-

N30-50-K Pressure Sustaining 2-Way Valve with Hydraulic Control

E-

N30-50-R

Pressure Sustaining 2-Way Valve with Hydraulic Control E-

N30-55-K Pressure Sustaining 2-Way Valve with Solenoid Control E-

N30-55-R Pressure Sustaining 2-Way Valve with Solenoid Control

E-7-

N30-KXZ Pressure Sustaining 3-Way Valve E-

N30-RXZ Pressure Sustaining 3-Way Valve E-10-

N30-50-KXZ Pressure Sustaining 3-Way Valve with Hydraulic Control

E-

N30-50-RXZ

Pressure Sustaining 3-Way Valve with Hydraulic Control E-

N30-54-KX

Pressure Sustaining 3-Way Valve N.C. with Hydraulic Relay E-

N30-55-KX Pressure Sustaining 3-Way Valve with Solenoid Control (982/985 Only)

E-

E Pressure Sustaining & Relief Valves

Water Control Solutions

N30-55-KX Pressure Sustaining 3-Way Valve with Solenoid Control

E-

N30-55-RX Pressure Sustaining 3-Way Valve with Solenoid Control (982/985 Only)

E-

N30-55-RX

Pressure Sustaining 3-Way Valve with Solenoid Control E-

930-D0-KX Pressure Sustaining 3-Way Valve Automatic Metering Valve (AMV)

E-

N3Q-K Pressure Relief Valve (Quick Type) E-

N3Q-R Pressure Relief Valve (Quick Type) E-

E Pressure Sustaining & Relief Valves

N50-60-R Level Control Valve with Modulating Horizontal Float

F-

N50-N3-60-K

Level Control Valve with Modulating Horizontal Float F-

450-66-Z Level Control Valve with Bi-Level Vertical Float

F-3-

750-66-B

Level Control Valve with Bi-Level Vertical Float F-

N50-80-XZ

Level Control Valve with Altitude Pilot F-6-

N53-66 Level Control & Pressure Sustaining Valve with Bi-Level Vertical Float

F-

N57-66-U

Level & Flow Control Valve with Bi-Level Vertical Float F-

F Level Control Valves

Water Control Solutions

H Flow Control & Pressure Reducing Valves

172-bDZ Flow Control & Pressure Reducing Valve (Differetial Pressure Duct)

H-

N72-bKUZ

Flow Control & Pressure Reducing Valve (Orifice Assembly) H-

N72-bRU Flow Control & Pressure Reducing Valve (Orifice Assembly)

H-

972-KVZ

Flow Control & Pressure Reducing Valve (Paddle Pilot) H-

972-RV Flow Control & Pressure Reducing Valve (Paddle Pilot)

H-

172-50-bDZ

Flow Control & Pressure Reducing with Hydraulic Control (Differetial Pressure Duct) H-

172-55-bD

Flow Control & Pressure Reducing with Solenoid Control (Differetial Pressure Duct) H-

N72-50-bKUZ Flow Control & Pressure Reducing with Hydraulic Control (Orifice Assembly)

H-

N72-50-bRU

Flow Control & Pressure Reducing with Hydraulic Control (Orifice Assembly) H-

N72-55-bKU Flow Control & Pressure Reducing with Solenoid Control (Orifice Assembly)

H-

N72-55-bKU

Flow Control & Pressure Reducing with Solenoid Control (Orifice Assembly) H-

N72-55-bRU

Flow Control & Pressure Reducing with Solenoid Control (Orifice Assembly) H-

972-50-KV Flow Control & Pressure Reducing with Hydraulic Control (Paddle Pilot)

H-

972-50-RV

Flow Control & Pressure Reducing with Hydraulic Control (Paddle Pilot) H-

972-MO-55-bKV Flow Control & Pressure Reducing with Hydraulic Control (Paddle Pilot)

H-15-

972-MO-55-RV Flow Control & Pressure Reducing with Hydraulic Control (Paddle Pilot)

H-

Main Network Irrigation Head Infield Head Infield System

A-

Positioning 3-Way Mini-Pilot Valve, Plastic

PC-X-A-P

Pilot Adjustment

Connections

0 Upstream for Reducing Vent for Sustaining 1 Sensing, Regulated Pressure 2 Vent for Reducing Upstraem for Sustaining 3 Valve Control Chamber

Turn Clock-Wise to increase setting and Counter Clock-Wise to decrease it.

Modulating Close (PRV) Modulating Open (PSV) Regulated pressure higher than setting: 0 3

Locked Position Regulated pressure equal to setting: 0 3 2 all passages locked

Modulating Open (PRV) Modulating Close (PSV) Regulated pressure lower than setting: 3 2

2 1

3 0

2 1

3 0

2 1

3 0

PC-X-A-P

Positioning 3-Way Mini-Pilot Valve, Plastic

Main Network Irrigation Head Infield Head Infield System

A-

PC-S-A-P Pressure Reducing Servo

2/3-Way Mini-Pilot Valve, Plastic

Pilot Adjustment

Connections

Turn Clock-Wise to increase setting and Counter Clock-Wise to decrease it.

PC-S-A-P

Pressure Reducing Servo 2/3-Way Mini-Pilot Valve, Plastic

0 Upstream for Reducing Downstream for Sustaining 1,2 Sensing, Regulated Pressure; Downstream for Reducing Upstraem for Sustaining 3 Valve Control Chamber

Modulating close Regulated pressure higher than setting: 0 3

Stable Position Regulated pressure equal to setting: 0 3 1, 2 controlled passage

Modulating Open Regulated pressure lower than setting: 3 1, 2

1 2

3 0

1 2

3 0

1 2

3 0

Main Network Irrigation Head Infield Head Infield System

A-

Pilot Adjustment

Connections

Turn Clock-Wise to increase setting and Counter Clock-Wise to decrease it.

PC-S-A-M

Pressure Reducing Servo 2/3-Way Mini-Pilot Valve, Metal

0 Upstream for Reducing Downstream for Sustaining 1 Sensing, Regulated Pressure 2 Downstream for Reducing Upstraem for Sustaining 3 Valve Control Chamber

Modulating close Regulated pressure higher than setting: 0 3

Stable Position Regulated pressure equal to setting: 0 3 2 controlled passage

Modulating Open lower than setting: 3 2

1 2

4 3 0

1 2

4 3 0

1 2

4 3 0

PC-S-A-M Pressure Reducing Servo

2/3-Way Mini-Pilot Valve, Metal

Main Network Irrigation Head Infield Head Infield System

A-

Pilot Adjustment

Connections

Turn Clock-Wise to increase setting and Counter Clock-Wise to decrease it.

PC-20-A-M

Pressure Reducing 2-Way Mini-Pilot Valve, Metal

1,2 Downstream / Remote Sensing / Pressure gauge 3 Valve Control Chamber 4 Upstream (through internal restriction)

1 2

4 3

1 2

4 3

1 2

4 3

Modulating Open Regulated pressure lower than setting: 4 3 1,

Stable Position Regulated pressure equal to setting: 4 3 1, controlled passage

Modulating Close Regulated pressure higher than setting: 4 3 2

PC-20-A-M

Pressure Reducing 2-Way Mini-Pilot Valve, Metal

Main Network Irrigation Head Infield Head Infield System

A-

Pilot Adjustment

Connections

Turn Clock-Wise to increase setting and Counter Clock-Wise to decrease it.

PC-30-A-P

Pressure Sustaining 2-Way Mini-Pilot Valve, Plastic

0 Downstream 1 Remote Sensing 2 Plugged 3 Upstream (downstream from inlet restriction and from control chamber connection)

1 2 3 0

1 2 3 0

1 2 3 0

Modulating close Regulated pressure Lower than setting: 0 3

Stable Position Regulated pressure equal to setting: 0 3 controlled passage

Modulating Open Regulated pressure higher than setting: 0 3

PC-30-A-P Pressure Sustaining 2-Way

Mini-Pilot Valve, Plastic
