Issue 7 14 Feb 2014
MATERIAL ALLOWABLE STRENGTH DATA
Design Allowables Data Sheet
A Metallic Materials
B Threaded Fasteners
C Wire Ropes and Cables
D Wood
E Rivets
Issue Status
Iss No. Date^ Change Description
1 29/06/06 Initial Issue, Metallic Materials Only
Following Sections Added:
Threaded Fasteners Wire Ropes & Cables Wood
3 07/06/07 Following Section Added: Rivets
Notes on Blind Rivets added.
Following Steels Added:
S S S T
Issue 7 14 Feb 2014
MATERIAL ALLOWABLE STRENGTH DATA
Correction to lb.in to N.mm conversion factor. Affects bolt and plywood bending allowables.
6 18/01/08 Notes on 4340 temper levels added
Issue 7 14 Feb 2014
MATERIAL ALLOWABLE STRENGTH DATA
- The density figures quoted are lowest value. This WILL NOT be conservative from a weight estimation point of view.
- Down factored allowables must be used in the heat affected zone of welded structures. If not given on this data sheet for the material in question, then the LAA allowable should not be used and a relevant specific figure obtained elsewhere.
- The correct abbreviation for each quantity, in the applicable Data Source, is given.
Factors Affecting Design Allowables from Data Sources
- Material Shape and Form:- The thickness of a material can have a large effect on it’s allowable strength. The way in which it was formed (e.g. rolled or extruded) can also have an influence.
- Anisotropy:- The strength of some metals can vary dependent on the direction of the applied load, relative to the crystal structure (i.e. grain) of the metal.
- Heat Treatment:- Heat treatment or temper conditions can have a dramatic effect on the properties of metal alloys.
- Statistical Basis:- Design data is generated from large numbers of physical tests. The more samples tested, the higher the confidence that can be assigned to the figures obtained. The statistical basis of the data concerns the number of samples, and the way in which the resulting data is manipulated to obtain the design allowable. The three bases usually quoted are named A, B and S. The LAA design allowables are the lowest figure of all the bases quoted in the Data Source.
Issue 7 14 Feb 2014
MATERIAL ALLOWABLE STRENGTH DATA
Contents
Steels
AISI 4130 (Normalised, tempered & stress relieved) AISI 4130 (Quenched & tempered) AISI 4130 Welded allowables AISI 4340 S 96 S 99 S 510 S 514 S 515 T 45
Aluminium Alloys
AISI 2014 AISI 2024 AISI 6061 AISI 7075 L 114 L 163 (was L 72) L 168 (was L 65)
Issue 7 14 Feb 2014
MATERIAL ALLOWABLE STRENGTH DATA
Material Designation 4130
Data Source Reference Mil-Hdbk-5 Iss H Table 2.3.1.0(C2)
Available Forms Tubing
Heat Treatments and Tempers Quenched & Tempered
Young’s Modulus X 10^
(^3) ksi E
GPa 200
Density
lb/in 3 ω
g/cm^3 7.
Ultimate Tensile Strength
ksi Ftu
MPa 862
Tensile Yield Strength
ksi Fty
MPa 689
Ultimate Shear Strength
ksi Fsu
MPa 517 Ultimate Bearing Strength
ksi Fbru
MPa 1338
Yield Bearing Strength
ksi Fbry
MPa 1007
Issue 7 14 Feb 2014
MATERIAL ALLOWABLE STRENGTH DATA
Material Designation 4130
Data Source Reference Mil-Hdbk-5 Iss H Table 8.2.2.1.1 (a)
Available Forms -
Heat Treatments and Tempers
Welded (Heat Affected Zone) No heat treatment after welding.
Ultimate Tensile Strength
ksi Ftu
MPa 496 Ultimate Shear Strength
ksi Fsu
MPa 296
Issue 7 14 Feb 2014
MATERIAL ALLOWABLE STRENGTH DATA
Material Designation S 96
Data Source Reference ESDU 00-932 Iss 2. 1988
Available Forms Bars & Forgings
Heat Treatments and Tempers
Young’s Modulus X 10^
(^3) ksi E
GPa 204
Density
lb/in 3 ρ
g/cm^3 7.
Ultimate Tensile Strength
ksi ft
MPa 849
Tensile Yield Strength
ksi t
MPa 680
Ultimate Shear Strength
ksi fso
MPa 560 Ultimate Bearing Strength
ksi MPa
Yield Bearing Strength
ksi b
MPa 973
Issue 7 14 Feb 2014
MATERIAL ALLOWABLE STRENGTH DATA
Material Designation S 99
Data Source Reference ESDU 00-932 Iss 2. 1988
Available Forms Bars & Forgings
Heat Treatments and Tempers
Young’s Modulus X 10^
(^3) ksi E
GPa 200
Density
lb/in 3 ρ
g/cm^3 7.
Ultimate Tensile Strength
ksi ft
MPa 1215
Tensile Yield Strength
ksi t
MPa 1080
Ultimate Shear Strength
ksi fso
MPa 770 Ultimate Bearing Strength
ksi MPa
Yield Bearing Strength
ksi b
MPa 1667
Issue 7 14 Feb 2014
MATERIAL ALLOWABLE STRENGTH DATA
Material Designation S 514
Data Source Reference ESDU 00-932 Iss 2. 1988
Available Forms Sheet & Strip
Heat Treatments and Tempers
Young’s Modulus X 10^
(^3) ksi E
GPa 200
Density
lb/in 3 ρ
g/cm^3 7.
Ultimate Tensile Strength
ksi ft
MPa 770
Tensile Yield Strength
ksi t
MPa 630
Ultimate Shear Strength
ksi fso MPa Ultimate Bearing Strength
ksi MPa
Yield Bearing Strength
ksi b
MPa 945
Issue 7 14 Feb 2014
MATERIAL ALLOWABLE STRENGTH DATA
Material Designation S 515
Data Source Reference ESDU 00-932 Iss 2. 1988
Available Forms Sheet & Strip
Heat Treatments and Tempers
Young’s Modulus X 10^
(^3) ksi E
GPa 200
Density
lb/in 3 ρ
g/cm^3 7.
Ultimate Tensile Strength
ksi ft
MPa 460
Tensile Yield Strength
ksi t MPa
Ultimate Shear Strength
ksi fso MPa Ultimate Bearing Strength
ksi MPa
Yield Bearing Strength
ksi b MPa
Issue 7 14 Feb 2014
MATERIAL ALLOWABLE STRENGTH DATA
Material Designation T
Data Source Reference
British Aircraft Corporation Basic Materials Data Sheet 1.2. Available Forms Tube Ø not less than 0.5”
Heat Treatments and Tempers
Welded (Heat Affected Zone) No heat treatment after welding.
Ultimate Tensile Strength
ksi Ftu
MPa 463
Ultimate Shear Strength
ksi Fsu
MPa 347
Issue 7 14 Feb 2014
MATERIAL ALLOWABLE STRENGTH DATA
Aluminium Alloys
Material Designation 2014
Data Source Reference
Mil-Hdbk-5 Iss H Tables 3.2.1. (b1,b2,c1,d,e,f)
Available Forms
Bars, Rods and Shapes, rolled, drawn or hand- finished. Die and Hand Forgings. Clad Figures Included.
Heat Treatments and Tempers
T6, T651, T6510,
T6511, T652 and T62.
Young’s Modulus X 10^
(^3) ksi E
GPa 72
Density
lb/in 3 ω
g/cm^3 2. Ultimate Tensile Strength
ksi Ftu
MPa 386
Tensile Yield Strength
ksi Fty
MPa 324 Ultimate Shear Strength
ksi Fsu
MPa 241
Ultimate Bearing Strength
ksi Fbru
MPa 572
Yield Bearing Strength
ksi Fbry
MPa 490
Issue 7 14 Feb 2014
MATERIAL ALLOWABLE STRENGTH DATA
Material Designation 6061
Data Source Reference
Mil-Hdbk-5 Iss H Tables 3.6.2. (b1,b2,c1,d,e,f g).
Available Forms
Sheet, Plate, Drawn Tube & Pipe. Rods & Special Shapes, rolled, drawn or cold finished. Die & Hand Forgings. Extruded Rod, Bar & Shapes.
Heat Treatments and Tempers
T4, T42, T451,
T4510, T4511 T6,
T62, T651, T6510,
T6511, T
Young’s Modulus X 10^ (^3) ksi E
GPa 68
Density
lb/in 3 ω
g/cm^3 2. Ultimate Tensile Strength
ksi Ftu
MPa 179
Tensile Yield Strength
ksi Fty
MPa 83
Ultimate Shear Strength
ksi Fsu
MPa 110
Ultimate Bearing Strength
ksi Fbru
MPa 290
Yield Bearing Strength
ksi Fbry
MPa 152
Issue 7 14 Feb 2014
MATERIAL ALLOWABLE STRENGTH DATA
Material Designation 7075
Data Source Reference
Mil-Hdbk-5 Iss H Tables 3.7.4. (b1,b2,b3,b4,c c2,c3,c4,c5,d,e1, e2,f1,f2,g1,g2,g3, g4)
Available Forms
Sheet & Plate. Bar, Rods & Shapes, rolled, drawn or cold finished. Die & Hand Forgings. Extruded Rods, Bars and Shapes. Clad Figures Included.
Heat Treatments and Tempers
T6, T62,
T651,T6510, T6511,
T652, T73, T7351,
T73510, T73511,
T7352, T76, T7651,
T76510, T
Young’s Modulus X 10^
(^3) ksi E
GPa 64
Density
lb/in 3 ω
g/cm^3 2.
Ultimate Tensile Strength
ksi Ftu
MPa 386
Tensile Yield Strength
ksi Fty
MPa 303 Ultimate Shear Strength
ksi Fsu
MPa 241 Ultimate Bearing Strength
ksi Fbru
MPa 579
Yield Bearing Strength
ksi Fbry
MPa 469
