US-

USB2.0 Audio/MIDI Interface

D01127720A

OWNER'S MANUAL

The exclamation point within an equilateral triangle is intended to alert the user to

the presence of important operating and maintenance (servicing) instructions in the

literature accompanying the appliance.

The lightning flash with arrowhead symbol, within equilateral triangle, is intended to

alert the user to the presence of uninsulated “dangerous voltage” within the product’s

enclosure that may be of sufficient magnitude to constitute a risk of electric shock to

persons.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR

BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

WARNING: TO PREVENT FIRE

OR SHOCK HAZARD, DO NOT

EXPOSE THIS

APPLIANCE TO RAIN OR

MOISTURE.

This appliance has a serial number located on the rear

panel. Please record the model number and serial number

and retain them for your records.

Model number

Serial number

In North America use only on 120V supply.

CE Marking Information

a) Applicable electromagnetic environment: E

b) Peak inrush current: 0.6 A

TO THE USER

This equipment has been tested and found to comply

with the limits for a Class A digital device, pursuant to Part

15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when

the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in

accordance with the instruction manual, may cause

harmful interference to radio communications.

Operation of this equipment in a residential area is likely

to cause harmful interference in which case the user

will be required to correct the interference at his own

expense.

CAUTION

Changes or modifications to this equipment not expressly

approved by TEAC CORPORATION for compliance could

void the user's authority to operate this equipment.

For U.S.A.

IMPORTANT SAFETY INSTRUCTIONS

Contents

Analog connections with keyboards, drum

• 1 − Introduction
  • Overview
  • Main features
  • Included items
  • About this manual
  • Trademarks
  • Precautions and notes for placement and use
  • Beware of condensation....................................................
  • Cleaning the unit..................................................................
• 2 − Names and Functions of Parts
  • Front panel
  • Rear panel
• 3 − Installation
  • System requirements..........................................................
    • Windows
    • Mac OS X
  • Connecting the power
  • Installing the driver
    • Installing the driver for Windows
    • Installing the driver for Mac OS X
    • Uninstalling the driver...............................................
    • answers (FAQ) Frequently asked installation questions and
  • Settings on your computer
  • Installing Cubase LE 5.......................................................
• 4 − US-1800 Control panel settings
  • Overview
  • Control panel settings
    • Audio Performance
    • Sample Clock Source
    • Digital Output Format
    • Digital Output Channels
• 5 − Connections
  • External device connection example
  • USB connections
  • Audio connections
    • Mic
    • Guitar
    • MiniDisc and CD players, etc. machines, sound modules and cassette,
    • MiniDisc and CD players, etc. Digital connections with sound modules and
    • Monitor speakers.........................................................
    • Headphones
  • MIDI connections
• 6 – Application Guide
  • Cubase LE
  • Windows XP and Windows Media Player - Player Windows Vista/Windows 7 and Windows Media - Mac OS X and iTunes......................................................... - Simultaneous use with multiple clients..................... - 7 – MIDI implementation chart.................... - 8 – Troubleshooting...................................... - 9 – Specifications - Input/output ratings - Analog audio input/output - Digital audio input/output - Control input/output - Audio performance - Computer requirements - Windows - Macintosh - General................................................................................... - Dimensional drawings - Block diagram......................................................................

Thank you for your purchase of the TASCAM US-

USB2.0 Audio/MIDI Interface.

Before connecting and using the unit, please take time to

read this manual thoroughly to ensure you understand

how to properly set up and connect the unit, as well as

the operation of its many useful and convenient functions.

After you have finished reading this manual, please keep

it in a safe place for future reference.

You can also download the Owner's Manual from the

TASCAM web site (http://www.tascam.com).

Overview

The unit is a USB-based audio interface designed for use

with Digital Audio Workstation (DAW) software, such as

Cubase LE 5. It provides abundant analog and digital

inputs and outputs, and 16-channel MIDI inputs and

outputs. It is the ideal companion to any computer-based

digital recording setup.

Main features

Audio interface with 16 inputs and 4 outputs

24-bit/96-kHz audio

12 balanced analog inputs include 8 XLR for mics and 4

line

S/PDIF digital input

+48V phantom power can be provided (to 8 mic inputs)

Outputs include 4 balanced line, a balanced pair for

monitors, digital and headphone

S/PDIF or AES/EBU selectable digital output

MIDI IN/OUT

Direct monitoring function allows input monitoring

without latency

In addition to a monitor level control, independent

level control is possible for the signals input from a

computer by USB and through the unit’s input jacks

Can be used with multiple software clients at the same

time even if some use ASIO and other use WDM for

audio control

USB 2.0 High speed (480 MHz) compatible

Cubase LE 5 included

A note about computer operation

If you are unsure about how to perform basic computer

operations appearing in this manual, please refer to the

owner’s manual that came with your computer.

1 − Introduction

Included items

The included items are listed below.

Take care when opening the package not to damage the

items. Keep the package materials for transportation in

the future.

Please contact the store where you purchased this unit

if any of these items are missing or have been damaged

during transportation.

Main unit

........................................................................................ 1

AC adaptor (TASCAM PS-1225L)

............................................ 1

Power cord set for AC adaptor

• ............................................... 1
• USB cable....................................................................................... 1
• CD-ROM(containing driver) ...................................................... 1
• DVD-ROM (Cubase LE 5)........................................................... 1
• Cubase LE 5 Quick Start Guide............................................... 1

A rack-mounting screw kit

....................................................... 1

A warranty card

• ........................................................................... 1

Owner's manual (this manual)

• ............................................... 1

CAUTION

Always use the included TASCAM PS-1225L AC adaptor and

its power cord with this unit because they match the unit’s

power requirements. Moreover, you should never use the

included AC adaptor and its power cord with other devices.

Incorrect use could cause malfunction, fire or electric shock.

About this manual

In this manual, we use the following conventions:

The names of keys and controls are given in the

following bold typeface: PHONES

Characters that appear on a computer display are given

in the following light typeface: OK

Additional information is introduced in the styles

below when needed:

TIP

Useful hints when using the unit.

NOTE

Explanation of actions in special situation and supplement.

CAUTION

Instructions that should be followed to avoid injury, damage

to the unit or other equipment, and loss of data.

2 − Names and Functions of Parts

Front panel

1 STANDBY/ON switch, indicator

Use this switch to turn the power ON and to put the

unit in standby. When ON, the STANDBY/ON indicator

lights green.

2 USB indicator

Lights up orange to indicate a valid USB connection to

the host computer.

3 PHANTOM switches

Use these switches to set whether or not +48 V

phantom power is provided to the MIC IN jacks (1-4,

5-8).

Each switch controls four input channels. Phantom

power is on when the button is pushed in.

CAUTION

Before turning these switches ON or OFF, turn the output

volume down using the PHONES and MONITOR knobs.

Depending on the mic, loud noises might be produced

and damage could be caused to equipment and people’s

hearing.

Do not connect or disconnect a mic with an input when its

switch is ON.

Turn a switch ON only when connecting a condenser

microphone that requires phantom power.

Do not supply phantom power to an unbalanced dynamic

microphone.

Some ribbon mics can be damaged by phantom power. If

unsure, do not supply phantom power to a ribbon mic.

4 MIC IN (balanced) jacks

These are XLR balanced analog mic input jacks. Use

the Gain knobs to adjust the input gain level.

(1: GND, 2: HOT, 3: COLD)

5 GUITAR (unbalanced)/LINE IN (balanced) jacks and

switches

These jacks (9-10) are standard TRS analog input jacks.

When the switch is pressed in, the corresponding jack

functions as an unbalanced guitar input ( GUITAR ).

When the switch is out, the corresponding jack

functions as a balanced input ( LINE IN ). Use the

corresponding gain knobs to set the gains of the

inputs.

(Tip: HOT, Ring: COLD, Sleeve: GND)

6 Gain knobs and OL indicators (1-10)

Adjust the gain level for Inputs ( 1-10 ) individually. The

adjustable range is from –2 dBu to –58 dBu for Mic

Inputs ( 1-8 ), from +4 dBu to –42 dBu for Line Inputs

( 9-10 ), and from –6dBV to –52dBV for Guitar Inputs

( 9-10 ).

The OL (overload) indicators light when an input signal

is close to distortion (when –2 dBFS is exceeded).

7 MONITOR knob

Adjusts the level of signals output from the MONITOR

L/R jacks on the rear panel.

8 MIX knob

Controls the balance of the signal sources being

output from the PHONES jack and the MONITOR L/

R jacks. With this knob turned to the far left, the unit

will output the signal input from the MIC IN (1-8) jacks

and LINE IN (9-14) jacks. With this knob turned to the

far right, the unit will output the signal received from

the computer via USB.

9 PHONES jack and knob

Use this standard stereo phone jack to connect stereo

headphones. This jack outputs the same signal that is

output from the MONITOR L/R jacks.

Use the PHONES knob to adjust the headphones

output level.

CAUTION

Turn the PHONES knob to the minimum volume before

connecting headphones. Failure to do so could cause sudden

loud noises and damage hearing, for example.

0 USB port

Use the included USB cable to connect the unit to a

computer.

(Only compatible with USB 2.0.)

q DIGITAL IN (coaxial) jack

This coaxial digital input jack is compatible with the

IEC60958-3 (S/PDIF) standard.

w DIGITAL OUT (coaxial) jack

This coaxial digital output jack is compatible with

the IEC60958-3 (S/PDIF) and AES3-2003 (AES/EBU)

standards. This jack outputs the same signals as LINE

OUTPUTS 1/2 or LINE OUTPUTS 3/4. Set this using the

control panel. The digital signal format can also be set

using the control panel.

NOTE

This unit’s DIGITAL IN and OUT jacks can input and output

signals at 24-bit/96 kHz.

e MIDI OUT connector

This standard 5-pin DIN connector can be used to

output MIDI signals.

r MIDI IN connector

This standard 5-pin DIN connector can be used to

input MIDI signals.

t INPUTS (BALANCED) jacks and LEV switches

INPUTS ( 11-14 ) are standard TRS balanced input jacks.

Use the LEV switches to set the nominal level to either

–10 dBV ( −10 ) or +4 dBu ( +4 ).

NOTE

The gain of these jacks cannot be adjusted.

y LINE OUT (BALANCED) jacks (1-4)

These standard TRS jacks are balanced analog line

output jacks. The nominal output level is +4 dBu. These

jacks output signals sent from a computer to the unit

by USB. Use the audio application on the computer to

set which signals to output. Connect these outputs to

an external mixer, recorder or other device.

(Tip: HOT, Ring: COLD, Sleeve: GND)

u MONITOR (BALANCED) jacks (L/R)

These standard TRS jacks are balanced analog jacks

that output the monitoring signals. These can output

both a mono mix of signals from the unit inputs

( 1-14 ) and the signals output from the computer for

monitoring. Use the MIX knob on the front panel

to adjust the balance of these two sources. Use the

MONITOR knob on the front panel to adjust the output

level.

Connect these jacks to monitor speakers, for example.

(Tip: HOT, Ring: COLD, Sleeve: GND)

i Cord holder

Loop the cord of the included TASCAM PS-1225L

AC adaptor here to prevent the plug from being

disconnected accidentally.

o DC IN 12V jack

Connect the included TASCAM PS-1225L AC adaptor

to this Jack.

2 − Names and Functions of Parts

Rear panel

CAUTION

Handle the enclosed CD-ROM with care. If the disc

becomes scratched or dirty, your computer may be unable

to read it and the software cannot be installed. If the

disc becomes unreadable, a fee will be charged for its

replacement.

Never attempt to play the enclosed CD-ROM in a

conventional audio CD player, as the resulting noise may

damage your speakers or your hearing.

Installing the driver for Windows

NOTE

During driver installation, a warning that “this software

... has not passed Windows Logo testing“ will appear.

This message appears when a driver that has not

received Windows Logo testing is installed. This message

appears because the drivers for TASCAM products have

not received Windows Logo testing. We have, however,

confirmed their proper operation. If this message appears,

click Continue to proceed with the installation.

During installation, you must connect the unit in step 7.

You should complete each of these installation steps in

less than one minute. Installation may fail if you take too

much time.

1 Confirm that the unit and the PC are not connected

by the USB cable.

2 Insert the included driver installation CD-ROM into

the PC where you will install it.

3 Click the Install Driver button when the screen

below appears. (If this screen does not appear

automatically, find and open the Autorun2.exe

program in the Autorun folder on the driver CD-

ROM.)

4 When the language selection screen (below)

appears, select the language you prefer and then

click the OK button.

5 Click the Install the Driver button when the screen

below appears.

6 Read the contents of the License Agreement,

and select I accept the agreement if you agree to

the terms. Next, click the Install button to start

installation.

7 When the screen below appears, use the supplied

USB cable to connect the unit to the PC. Then, turn

the unit on.

8 When the screen below appears, the installation

is complete. Click the Reboot now button to restart

the PC to use the driver.

3 − Installation

Mac OS X

1 Insert the CD-ROM into the PC and double click

TASCAM US-1800 Remover icon.

2 Follow the instructions on the screen for the

remaining procedure.

Frequently asked installation questions and

answers (FAQ)

Windows driver installation

Q: When I connect the unit to a computer, the Windows

Hardware Wizard appears and I cannot install the driver.

Am I making a mistake in the installation procedures?

A: Close the Windows Hardware Wizard and disconnect

the unit. You must install the driver before connecting

this unit. Insert the CD-ROM included with the

product. The menu for installing the driver appears

automatically.

Select Install Driver, and follow the instructions shown

on the screen. If you have downloaded the driver from

the TASCAM website (htt://www.tascam.com), expand

the ZIP archive, launch the setup.exe file, and follow

the instructions on the screen.

Q: I loaded the installation CD-ROM into a Windows

computer, but the driver installation menu does not

appear. How can I access this menu?

A: The automatic playback settings for the disc drive

might be disabled.

Open the CD-ROM using Windows Explorer, and

double-click the Autorun2.exe file to manually open

the installation menu.

Settings on your computer

Here are a few basic points to help you set up your

computer for best performance with audio applications.

Do not run other applications. You will probably use

your computer for applications other than audio,

but we recommend that you avoid running other

applications at the same time you are running

audio programs. Processing digital audio places a

considerable load on your computer.

This means that if you are running other applications

(especially graphics or Internet tools) at the same time

as your audio application, the processing may not

happen fast enough.

Installing Cubase LE 5

For details see the Cubase LE 5 Quick Start Guide.

9 After the PC has restarted, open the TASCAM

US-1800 ( Start > Control Panel ) or US-1800 Control

Panel ( Start > All Programs > TASCAM ). If the Driver

Version, Device and other data appear correctly,

the installation has succeeded.

Installing the driver for Mac OS X

1 Confirm that the US-1800 is not connected to the

computer.

2 Double-click the TASCAM_US1800_Driver_x.xx.dmg on

the included CD-ROM. As the TASCAM_US-1800_x.xx

is created on the desktop, open the folder.

3 Double-click the TASCAM_US-1800_x.xx.mpkg in the

folder to launch the installer.

4 Follow the instructions on the screen to conduct

the installation.

5 Restart the computer and then connect the unit.

Uninstalling the driver

Windows

There are two ways to uninstall the driver as shown below.

Using the Installation CD-ROM:

1 Follow steps 1 to 4 under “Installing the driver for

Windows” (See page 10.)

2 At step 5 of the procedure, click Remove the driver.

3 Follow the instructions on the screen for the

remaining procedure.

Using Windows Add or Remove Programs :

1 Open the Control Panel from the Start menu.

2 Double click on Add or Remove programs or Programs

and Features.

3 Select US-1800 driver from the list and click Change

or Remove Programs or Uninstall/change.

4 Follow the instructions on the screen for the

remaining procedure.

3 − Installation

5 − Connections

External device connection example

The following is an example of making connections with the unit.

Precautions before connecting devices to the unit

Turn the power OFF (or set the standby) for this unit and all devices that you will connect.

Connect all the devices so that they receive power from the same line. When using a power strip, for example, use one

with a thick cable and high electric current capacity to minimize power voltage fluctuation.

Digital recorder

Drum machine

Vocal microphones

Drums

Guitar

Bass guitar

Headphones

Keyboard Sound module

USB

Computer

5 − Connections

USB connections

Using the included USB cable, connect the US-1800 to

your computer as shown in the illustration.

NOTE

Some USB devices access the USB bus frequently. In order

to avoid dropouts, clipping noise and other problems with

the audio signal, we strongly recommend that you do not

connect any other USB devices, with the exception of a

mouse and keyboard, to the same computer as this unit.

Audio connections

Connect the output signal of your mic, guitar, keyboard,

or other audio device to the US-1800, where it will be

converted into digital audio and sent via USB to your

computer. Connect the output of the US-1800 to your

speakers (via an amp) or headphones, so you will be able

to monitor the audio signals coming into the US-1800 or

being produced by your computer.

Use the MIX knob to adjust the balance between the

computer output signal and the input signals from

microphones, guitars and other connected equipment.

Mic

Connect your mics to the MIC IN (1-8) jacks (XLR) on the

front panel. If you are using a condenser mic that requires

phantom power, turn on the PHANTOM (+48V ) switch.

You can use more than eight microphones by connecting

them via an external mic pre-amp. In this case, connect

the output of the mic pre-amp to the INPUTS ( 11-14 ) jacks

on the rear panel.

CAUTION

When the PHANTOM (+48) switch is ON, making an

unbalanced connection with a dynamic microphone

could cause the device to break.

Do not connect or disconnect any microphones when

the PHANTOM (+48) switch is ON. Doing so could cause a

loud noise or break the device.

Minimize the levels of the PHONES and MONITOR knobs

on the front panel before turning the PHANTOM (+48)

switch ON or OFF. Depending on the microphone, failure

to do so could result in a loud noise that might harm other

devices and damage human hearing.

Guitar

When connecting a guitar or bass guitar directly to this

unit, use a GUITAR/LINE IN (9-10) standard jack on the front

panel and set the GUITAR/LINE IN switch to GUITAR.

Analog connections with keyboards, drum

machines, sound modules and cassette,

MiniDisc and CD players, etc.

Connect the analog signal outputs of these types of

devices to the GUITAR/LINE IN jacks ( 9-10 ) on the front

panel or to the INPUTS jacks ( 11-14 ) on the rear panel.

When connecting them to the GUITAR/LINE IN jacks ( 9-10 ),

set the GUITAR/LINE IN switch to LINE IN.

NOTE

When a device is connected to a GUITAR/LINE IN jack

(9-10), you can use this unit’s gain control to adjust it in a

continuous range from –6 dBV to –52 dBV.

When a device is connected to an INPUTS jack (11-14), you

can set the nominal level to either –10 dBV (−10) or +

dBu (+4).

Digital connections with sound modules and

MiniDisc and CD players, etc.

Connect the digital inputs and outputs of these types of

devices to the DIGITAL IN and OUT jacks on the rear panel

of this unit.

NOTE

This unit’s digital input is an RCA pin jack that accepts S/

PDIF signals.

This unit’s digital outputs can output to either S/PDIF or

AES/EBU signals. Use the control panel to set the output

type.

Monitor speakers

Connect speakers for monitoring (powered speakers or an

amplifier and speakers) to the MONITOR OUTPUTS jacks on

the rear panel.

Headphones

Connect headphones to the standard stereo PHONES jack

on the front panel.

MIDI connections

Connect sound modules, keyboards, synthesizers, drum

machines and other MIDI devices to this unit as shown

in the illustration. MIDI signals input through the MIDI IN

connector on the rear panel of this unit are sent as is to

the computer. The MIDI signals sent from the computer to

this unit are output through the MIDI OUT connector on

the rear panel. As a result, by sending and receiving MIDI

time code (MTC), you can synchronize computer recording

software that is MTC-compatible with MIDI devices.

Mac OS X and iTunes

1 Open the Utilities folder, which is inside the

Applications folder, and double-click Audio MIDI

Setup to launch it.

2 When using Mac OS 10.6, open the Audio Devices

window and control-click US- 1800 to open a pop-

up menu. Click Use this device for sound input and

Use this device for sound output. The microphone and

speaker icons should move to the US-1800.

When using Mac OS 10.5, click the Audio Devices tab

and set the Default input , Properties , Default output ,

and System output to US-.

3 Launch iTunes, select an audio file and start

playback.

Simultaneous use with multiple clients

On Windows, this unit can simultaneously mix the outputs

of multiple audio applications that use different driver

protocols.

6 – Application Guide

7 – MIDI implementation chart

Function Transmitted Received Remarks

Basic Channel

At power ON X X

Through

Changed X X

Mode

At power ON X X

Messages X X Through

Altered *************

Note Number

X X

Through

Range *************

Velocity

Note ON X X

Through

Note OFF X X

After Touch

Polyphonic X X

Through

Channel X X

Pitch Bender X X Through

Control Change X X Through

Program Change

X X

Through

Range # *************

System Exclusive X X Through

System Common

Song Pos X X

Song Sel X X Through

Tune X X

System Real Time

Clock X X

Through

Commands X X

Other

Local on/off X X

Through

All note off X X

Active sensing X X

Reset X X

Notes

Mode 1: Omni on, Poly Mode 2: Omni on, Mono O: Yes

Mode 3: Omni off, Poly Mode 4: Omni off, Mono X: No

The sound breaks up or there is noise.

The load on the computer causes sound to break up and

noise to occur.

Methods to reduce the load on the computer are

introduced below.

1. If a wireless LAN, antivirus software and other software

that run in the background are operating, they

regularly put burdens on the computer, which can

cause sound to break up and noise.

Stop wireless LAN transmission, antivirus software and

other software running in the background when using

this unit.

2. Try increasing the buffer size (latency) setting in this

unit's control panel or in the audio application that

you are using.

NOTE

Please check with the maker of the audio application that

you are using for methods to reduce the application’s burden

on your computer

3. Change the settings of your computer so that they are

optimal for audio processing.

Windows XP

1 Right-click My Computer and select Properties.

2 Click the Advanced tab.

3 Click Settings in the Performance section.

4 On the Performance Option screen, select the Adjust

for Best Performance option.

Windows Vista

a) Turn Aero off.

1 Right-click the desktop and select Personalize to

open the Personalize appearance and sounds screen.

2 Choose Window Color and Appearance and then click

Open classic appearance properties for more options.

3 Select Windows Vista Basic or any option other than

Windows Aero.

b) Performance settings

1 Right-click Computer , select Properties , and then

click Advanced system settings.

2 Click the Advanced tab.

3 Click Settings in the Performance section.

4 On the Performance Option screen, select the Adjust

for Best Performance option.

Windows 7

a) Turn Aero off.

1 Right-click the desktop and select Personalize.

2 Select any theme from among Basic and High

Contrast Themes.

b) Performance settings

1 Right-click Computer and select Properties.

2 Click Advanced system settings.

3 Click the Advanced tab.

4 Click Settings in the Performance section.

5 On the Visual Effects tab of the Performance Options

screen, select the Adjust for best performance option.

Mac OS X

1 Open System Preferences... ” from the Apple menu

and select Energy Saver.

2 Click the Sleep tab.

3 Set Put the computer to sleep when it is inactive for: to

Never.

4 Set Put the display(s) to sleep when the computer is

inactive for: to Never.

5 Click the Options tab.

If a Processor performance setting is available, set it

to Highest.

NOTE

Depending on the Mac OS version and model this setting

might not be available.

Questions related to Cubase LE 5

Since Cubase LE 5 is a product provided by Steinberg

Media Technologies GmbH, it is not supported by

TASCAM.

Please use the Cubase LE 5 Help menu (and access the

PDF manuals) for information about how to use this

software.

8 – Troubleshooting

9 – Specifications

Input/output ratings

Analog audio input/output

MIC inputs (Balanced) terminals (MIC IN 1-8)

Connector: XLR-3-31 (1: GND, 2: HOT, 3: COLD)

Input impedance: 2.2 kΩ

Nominal input level: –2 dBu (0.615 Vrms)

Minimum input level: –58 dBu (0.00098 Vrms)

Maximum input level: +14 dBu (3.882 Vrms)

Guitar inputs (Unbalanced) terminals (GUITAR 9-10)

Connector: 6.3 mm (1/4”) TS Standard phone jack

(Tip: HOT, Sleeve: GND)

Input impedance: 700 kΩ

Nominal input level: –6 dBV (0.501 Vrms)

Minimum input level: –52 dBV (0.0025 Vrms)

Maximum input level: +10 dBV (3.162 Vrms)

Line input (Balanced) terminals (LINE IN 9-10)

Connector: 6.3 mm (1/4”) TRS Standard phone jack

(Tip: HOT, Ring: COLD, Sleeve: GND)

Input impedance: 10 kΩ

Nominal input level: +4 dBu (1.228 Vrms)

Minimum input level: –42 dBu (0.0062 Vrms)

Maximum input level: +20 dBu (7.746 Vrms)

Line input (Balanced) terminals (LINE IN 11-14)

Connector: 6.3 mm (1/4”) TRS Standard phone jack

(Tip: HOT, Ring: COLD, Sleeve: GND)

Input impedance: 10 kΩ

Nominal input level: –10 dBV (0.3162 Vrms)/

+4 dBu (1.228 Vrms)

Maximum input level: +6 dBV (1.995 Vrms)/

+20 dBu (7.746 Vrms)

Line output (Balanced) terminals (LINE OUT 1-4)

Connector: 6.3 mm (1/4”) TRS Standard phone jack

(Tip: HOT, Ring: COLD, Sleeve: GND)

Output impedance: 100Ω

Nominal output level: +4 dBu (1.228 Vrms)

Maximum output level: +24 dBu (12.277 Vrms)

Monitor output (Balanced) terminals (MONITOR L/R)

Connector: 6.3 mm (1/4”) TRS Standard phone jack

(Tip: HOT, Ring: COLD, Sleeve: GND)

Output impedance: 100Ω

Nominal output level: +4 dBu (1.228 Vrms)

Maximum output level: +24 dBu (12.277 Vrms)

Headphone output jack (PHONES)

Connector: 6.3 mm (1/4”) Standard Stereo phone jack

Maximum output: 50 mW + 50 mW

(1 kHz, 1%, 32Ω load)

Digital audio input/output

Coaxial (DIGITAL IN) terminal

Connector: RCA pin jack

Compatible signal format: IEC60958-3 (S/PDIF)

Input impedance: 75Ω

Level: 0.5 Vp-p/75Ω

Coaxial (DIGITAL OUT) terminal

Connector: RCA pin jack

Compatible signal format: Selectable in the Control

Panel between IEC60958 Consumer (S/PDIF) and

IEC958 Professional (AES/EBU)

Output impedance: 75Ω

Level: 0.5 Vp-p/75Ω

Control input/output

MIDI input (MIDI IN) jack

Connector: DIN 5 pin

Format: Standard MIDI format

MIDI output (MIDI OUT) jack

Connector: DIN 5 pin

Format: Standard MIDI format

USB terminal

Connector: USB B type 4 pin

Format: USB 2.0 High speed (480 MHz)

Audio performance

Frequency response

20 Hz - 20 kHz, +1/–1 dB (44.1/48 kHz)

20 Hz - 40 kHz, +1/–3 dB (88.2/96 kHz)

( MIC IN - LINE OUT , GAIN knob set to minimum, JEITA)

Signal-to-noise ratio

96 dB or more ( MIC IN - LINE OUT , GAIN knob set to

minimum, 44.1 kHz, JEITA)

Total harmonic distortion

Less than 0.01% ( MIC IN - LINE OUT , GAIN knob set to

minimum, JEITA)
