Relational Database Model
In this chapter, you will learn:
- That the relational database model takes a logical view of data
- That the relational model’s basic components are entities, attributes, and relationships among entities
- How entities and their attributes are organized into tables
A Logical View of Data
- Relational model
- Enables us to view data logically rather than physically
- Reminds us of simpler file concept of data storage
- Table
- Has advantages of structural and data independence
- Resembles a file from conceptual point of view
- Easier to understand than its hierarchical and network database predecessors
Tables and Their
Characteristics
- Table : two-dimensional structure composed of rows and columns
- Contains group of related entities an entity set - Terms entity set and table are often used interchangeably
Characteristics of a Relational Table
Table 3.
STUDENT Table Attribute Values
Student Classification
Keys (continued)
- Composite key
- Composed of more than one attribute
- Key attribute
- Any attribute that is part of a key
- Superkey
- Any key that uniquely identifies each entity
- Candidate key
- A superkey without redundancies
Controlled Redundancy
- Makes the relational database work
- Tables within the database share common attributes that enable us to link tables together
- Multiple occurrences of values in a table are not redundant when they are required to make the relationship work
- Redundancy is unnecessary duplication of data Docsity.com
An Example of a
Simple Relational Database
Keys (continued)
- Foreign key (FK)
- An attribute whose values match primary key values in the related table
- Referential integrity
- FK contains a value that refers to an existing valid tuple (row) in another relation
- Secondary key
- Key used strictly for data retrieval purposes
