The Science and Engineering of

Materials, 4

th

ed

Chapter 22 – Corrosion and Wear

Objectives of Chapter 22

• To introduce the principles and mechanisms by which

corrosion and wear occur under different conditions. This

includes the aqueous corrosion of metals, the oxidation

of metals, the corrosion of ceramics, and the degradation

of polymers.

• To give summary of different technologies that are used

to prevent or minimize corrosion and associated

problems.

• Chemical corrosion - Removal of atoms from a material by virtue of the solubility or chemical reaction between the material and the surrounding liquid.
• Dezincification - A special chemical corrosion process by which both zinc and copper atoms are removed from brass, but the copper is replated back onto the metal.
• Graphitic corrosion - A special chemical corrosion process by which iron is leached from cast iron, leaving behind a weak, spongy mass of graphite.

Section 22.

Chemical Corrosion

©2003 Brooks/Cole, a division of Thomson Learning, Inc. Thomson Learning

is a trademark used herein under license.™

Figure 22.1 Molten lead is held in thick steel pots during refining. In this case, the molten lead has attacked a weld in a steel plate and cracks have developed. Eventually, the cracks propagate through the steel, and molten lead leaks from the pot.

 Electrochemical corrosion - Corrosion produced by the development of a current in an electrochemical cell that removes ions from the material.

 Electrochemical cell - A cell in which electrons and ions can flow by separate paths between two materials, producing a current which, in turn, leads to corrosion or plating.

 Oxidation reaction - The anode reaction by which electrons are given up to the electrochemical cell.

 Reduction reaction - The cathode reaction by which electrons are accepted from the electrochemical cell.

Section 22.

Electrochemical Corrosion

©2003 Brooks/Cole, a division of Thomson Learning, Inc. Thomson Learning™ is a trademark used herein under license.

Figure 22.3 The components in an electrochemical cell: (a) a simple electrochemical cell and (b) a corrosion cell between a steel water pipe and a copper fitting.

 Electrode potential - Related to the tendency of a material to corrode. The potential is the voltage produced between the material and a standard electrode.

 emf series - The arrangement of elements according to their electrode potential, or their tendency to corrode.

 Nernst equation - The relationship that describes the effect of electrolyte concentration on the electrode potential in an electrochemical cell.

 Faraday’s equation - The relationship that describes the rate at which corrosion or plating occurs in an electrochemical cell.

Section 22.

The Electrode Potential in

Electrochemical Cells

©2003 Brooks/Cole, a division of Thomson Learning, Inc. Thomson Learning

is a trademark used herein under license.™

Figure 22.5 The half-cell used to measured the electrode potential of copper under standard conditions. The electrode potential of copper is the potential difference between it and the standard hydrogen electrode in an open circuit. Since E 0 is great than zero, copper is cathodic compared with the hydrogen electrode.

Design a process to electroplate a 0.1-cm-thick layer of copper onto a 1 cm × 1 cm cathode surface.

Example 22.2 SOLUTION

In order for us to produce a 0.1-cm-thick layer on a 1 cm 2 surface area, the weight of copper must be:

Example 22. Design of a Copper Plating Process

From Faraday’s equation, where M Cu = 63:54 g/mol and n = 2:

Example 22.2 SOLUTION

Therefore, we might use several different combinations of current and time to produce the copper plate:

Our choice of the exact combination of current and time might be made on the basis of the rate of production and quality of the copper plate. A current of ~ 1 A and a time of ~ 45 minutes are not uncommon in electroplating operations.

Example 22.3 SOLUTION

2. The total surface area of iron in contact with the corrosive liquid and the current density are:

Suppose that in a corrosion cell composed of copper and zinc, the current density at the copper cathode is 0.05 A/cm 2. The area of both the copper and zinc electrodes is 100 cm^2. Calculate (1) the corrosion current, (2) the current density at the zinc anode, and (3) the zinc loss per hour.

Example 22.4 SOLUTION

1. The corrosion current is:

Example 22. Copper-Zinc Corrosion Cell

2. The current in the cell is the same everywhere. Thus:

 Polarization - Changing the voltage between the anode and cathode to reduce the rate of corrosion.

• Activation polarization is related to the energy required to cause the anode or cathode reaction
• Concentration polarization is related to changes in the composition of the electrolyte
• Resistance polarization is related to the electrical resistivity of the electrolyte.

Section 22.

The Corrosion Current and

Polarization

 Intergranular corrosion - Corrosion at grain boundaries because grain boundary segregation or precipitation produces local galvanic cells.

 Stress corrosion - Deterioration of a material in which an applied stress accelerates the rate of corrosion.

 Oxygen starvation - In the concentration cell, low- oxygen regions of the electrolyte cause the underlying material to behave as the anode and to corrode.

 Crevice corrosion - A special concentration cell in which corrosion occurs in crevices because of the low concentration of oxygen.

Section 22.

Types of Electrochemical Corrosion
