An in-depth analysis of cache coherence protocols, specifically focusing on msi, mesi, and moesi. It covers the concepts of stores, state transitions, and the advantages and disadvantages of update-based and invalidation-based protocols. The document also includes examples to help illustrate the concepts.
Typology: Slides
1 / 9
This page cannot be seen from the preview
Don't miss anything!
Look at stores a little more closely There are three situations at the time a store issues: the line is not in the cache, the line is in the cache in S state, the line is in the cache in one of M, E and O states If the line is in I state, the store generates a read-exclusive request on the bus and gets the line in M state If the line is in S or O state, that means the processor only has read permission for that line; the store generates an upgrade request on the bus and the upgrade acknowledgment gives it the write permission (this is a data-less transaction) If the line is in M or E state, no bus transaction is generated; the cache already has write permission for the line (this is the case of a write hit; previous two are write misses)
Two main classes of protocols: Invalidation-based and update-based Dictates what action should be taken on a write Invalidation-based protocols invalidate sharers when a write miss (upgrade or readX ) appears on the bus Update-based protocols update the sharer caches with new value on a write: requires write transactions (carrying just the modified bytes) on the bus even on write hits (not very attractive with writeback caches) Advantage of update-based protocols: sharers continue to hit in the cache while in invalidation-based protocols sharers will miss next time they try to access the line Advantage of invalidation-based protocols: only write misses go on bus (suited for writeback caches) and subsequent stores to the same line are cache hits
Few things to note Flush operation essentially launches the line on the bus Processor with the cache line in M state is responsible for flushing the line on bus whenever there is a BusRd or BusRdX transaction generated by some other processor On BusRd the line transitions from M to S, but not M to I. Why? Also at this point both the requester and memory pick up the line from the bus; the requester puts the line in its cache in S state while memory writes the line back. Why does memory need to write back? On BusRdX the line transitions from M to I and this time memory does not need to pick up the line from bus. Only the requester picks up the line and puts it in M state in its cache. Why?
BusRd takes a cache line in M state to S state The assumption here is that the processor will read it soon, so save a cache miss by going to S May not be good if the sharing pattern is migratory : P0 reads and writes cache line A, then P1 reads and writes cache line A, then P2… For migratory patterns it makes sense to go to I state so that a future invalidation is saved But for bus-based SMPs it does not matter much because an upgrade transaction will be launched anyway by the next writer, unless there is special hardware support to avoid that: how? The big problem is that the sharing pattern for a cache line may change dynamically: adaptive protocols are good and are supported by Sequent Symmetry and MIT Alewife
Take the following example P0 reads x, P1 reads x, P1 writes x, P0 reads x, P2 reads x, P3 writes x Assume the state of the cache line containing the address of x is I in all processors
P0 generates BusRd , memory provides line, P0 puts line in S state P1 generates BusRd , memory provides line, P1 puts line in S state P1 generates BusUpgr , P0 snoops and invalidates line, memory does not respond, P1 sets state of line to M P0 generates BusRd , P1 flushes line and goes to S state, P0 puts line in S state, memory writes back P2 generates BusRd , memory provides line, P2 puts line in S state P3 generates BusRdX , P0, P1, P2 snoop and invalidate, memory provides line, P3 puts line in cache in M state
If a cache line is in M state definitely the processor with the line is responsible for flushing it on the next BusRd or BusRdX transaction If a line is not in M state who is responsible? Memory or other caches in S or E state? Original Illinois MESI protocol assumed cache-to-cache transfer i.e. any processor in E or S state is responsible for flushing the line However, it requires some expensive hardware, namely, if multiple processors are caching the line in S state who flushes it? Also, memory needs to wait to know if it should source the line Without cache-to-cache sharing memory always sources the line unless it is in M state
Take the following example P0 reads x, P0 writes x, P1 reads x, P1 writes x, …
P0 generates BusRd , memory provides line, P0 puts line in cache in E state P0 does write silently, goes to M state P1 generates BusRd , P0 provides line, P1 puts line in cache in S state, P0 transitions to S state Rest is identical to MSI
Consider this example: P0 reads x, P1 reads x, …
P0 generates BusRd , memory provides line, P0 puts line in cache in E state P1 generates BusRd , memory provides line, P1 puts line in cache in S state, P transitions to S state (no cache-to-cache sharing) Rest is same as MSI
Some SMPs implement MOESI today e.g., AMD Athlon MP and the IBM servers Why is the O state needed? O state is very similar to E state with four differences: 1. If a cache line is in O state in some cache, that cache is responsible for sourcing the line to the next requester; 2. The memory may not have the most up-to-date copy of the line (this implies 1); 3. Eviction of a line in O state generates a BusWB ; 4. Write to a line in O state must generate a bus transaction When a line transitions from M to S it is necessary to write the line back to memory For a migratory sharing pattern (frequent in database workloads) this leads to a series of writebacks to memory These writebacks just keep the memory banks busy and consumes memory bandwidth Take the following example P0 reads x, P0 writes x, P1 reads x, P1 writes x, P2 reads x, P2 writes x, … Thus at the time of a BusRd response the memory will write the line back: one writeback per processor handover O state aims at eliminating all these writebacks by transitioning from M to O instead of M to S on a BusRd /Flush Subsequent BusRd requests are replied by the owner holding the line in O state The line is written back only when the owner evicts it: one single writeback
